Beyond Digital Rights Management (DRM) solutions, there has always been a demand for applications such as Secure Video Playback and Secure Video Recording. Let’s explore how Linaro’s Secure Data Path patchset enables these use cases.

Beyond Digital Rights Management (DRM) solutions, there has always been a demand for applications such as Secure Video Playback and Secure Video Recording. Let’s explore how Linaro’s Secure Data Path patchset enables these use cases.

Introduction

OP-TEE, a secure world OS implementation, is maintained by Linaro and adheres to the GlobalPlatform specifications.

There has always been a need for applications beyond Digital Rights Management (DRM) solutions, like Secure Video Playback. It also facilitates Trusted UI and Secure Video Recording. For instance, Trusted UI provides a more secure way to authenticate with services like your bank. Additionally, Secure Video Recording can prove that a video stream has not been altered since its capture.

Secure Data Path (SDP) is implemented using Protected memory. The term Protected memory is used to distinguish it from Secure memory. It’s also an established term in other solutions. The patches for Secure Data Path with OP-TEE are now upstream. They were merged during the Linux kernel 6.18 merge window.

In this blog, we will cover the earlier designs and attempts to upstream SDP to the Linux kernel.

History

We have seen a few SDP designs with OP-TEE over the years. Check out some of our presentations from previous Linaro Connects to learn more about these:

Upstreaming SDP with OP-TEE has also been attempted a few times over the years without much success.

All the attempts have been built on an out-of-tree version of the patch “tee: new ioctl to a register tee_shm from a dmabuf file descriptor”. The patch originates from a pull request authored by Etienne Carriere (ST) in 2016 to the Linaro Security Working Group’s fork of the Linux kernel.

The principle has been to provide a DMA heap to allocate DMA-bufs that can be used in an SDP use-case.

In 2022, Oliver Masse (NXP) posted a patchset with a secure static carveout using the “linaro,secure-heap” compatible in Device Tree. The secure memory was managed by genalloc to avoid unnecessary secure world entries. However, this patch set did not lead to further developments after the initial discussions.

Between 2023 and 2024, Yong Wu (Mediatek) introduced a series of patch sets, “dma-buf: heaps: Add restricted heap”, which included two secure heaps. These heaps, one static carveout and one allocated with CMA, differed from Olivier’s patch set in that they used OP-TEE to manage allocations and protect memory during initialization. Reviewers ultimately decided to name this “restricted memory” to distinguish it from other types of secure memory. Version 5 of the patch set turned out to be the last in this series.

In 2024, right after Yong’s v5, Jens Wiklander (Linaro) posted the first version of the Secure Data Path patch set. This patchset was a small increment on top of Yong’s v5. Feedback for the posted versions up to the last v12 resulted in the following changes:

  • A demonstration of protected DMA-bufs based on Gstreamer on a RockPI-4 board
  • Changed from restricted to protected buffers to align with Vulkan documentation
  • Moved instantiation of the DMA heap into the TEE subsystem
  • Dynamic or temporarily carved out protected memory for the DMA heap, so the memory can be returned when the use case is finished
  • Support in the FF-A OP-TEE driver

The purpose of upstreaming these patches is to reduce fragmentation. Having a common approach in security-sensitive operations also reduces the likelihood of security bugs.

Stay tuned

This blog provided a quick overview of the Secure Data Path. In part 2, we will delve deeper into the technical details of the design.

Thank you for reading this far. If you have any questions or thoughts, feel free to create an issue at https://github.com/OP-TEE/optee_os/issues or to reach out on the mailing list. You’re also welcome to join the OP-TEE Contributions Forum (https://www.trustedfirmware.org/meetings).
